Home Use 220V 5kw 5.12kwh Inverter Solar Power Energy Storage System

Basic Info

Model NO.	CHCI-5KW-5.12KWH
Type	Lithium-Ion Batteries
Nominal Voltage	12V
Discharge Rate	High Discharge Rate
Shape	Square Battery
Electrolyte	Li-ion
Installation	Fixed
Rechargeable	Chargeable
Usage	Home Energy Storage
Transport Package	Carton
Specification	550*233*1125mm
Trademark	CEEG
Origin	China
HS Code	8541430000
Production Capacity	1gw/Year

Product Description

Home Use 220V 5kw 5.12kwh inverter Solar Power Energy Storage System

Model	CHCI-5.0K-5.12kwh	AC Input/Output	CHCI-5.0K-5.12kwh
Absolute Max Voltage [V]	600	Rated Power [W]	5000
MPPT Voltage Range [V]	100...550	Max. Apparent Power to Grid [VA]	5500
Max. DC Input Power [W]	6650	Max. Apparent Power from Grid [VA]	10000
Start-up Voltage [V]	90	Rated Voltage [V]	220/230/240
Rated Operating Voltage [V]	360	Rated Frequency [Hz]	50/60
Max. Input Current [A]	12.5/12.5	Rated AC Current to Grid[A]	21.7
Isc PV[A]	18/18	Rated AC Current from Grid[A]	43.4
NO.of MPP Trackers	2	Displacement Power Factor	1(-0.8...+0.8 adjustable)
NO.of Strings per MPP Tracker	1	THDi	< 3%

Product Highlights

1.Inverter and Battery box integrated.2. White design in household appliances.3. Modular design, increase or decrease the quantity.4. Convenient for installation, maintenance, and expansion.5. Selection of long-life Lithium batteries, produced by reputed manufacturers6. Intelligent management, handy and pretty.7. Multiple safety design8. Warranty: 10 Years

Product Details:
Conpany Introduction





Other Products:

Packing & Shipping

Certifications

Q&A

1. Q: What is your MOQ (Minimum Order Quantity)?
   A: Sample order for testing is acceptable. You can choose to place just one piece for testing.
2. Q: What is the warranty term of your product?
   A:CEEG standard warranty term is 10 years. Besides, warranty is extending available according to customers' requirements.
3. Q:What about the lead time of bulk order?
   A:It depends on the order quantity. Normally, the lead time is around 30 days.
4. Q: What is the payment term of the order?
   A: T/T 30% as deposit, T/T 70% before shipment, other payment terms can be discussed according to the order quantity.
